Amana ARGS7650E Timer

Amana ARGS7650E Electronic Range/Oven Features:

Amana ARGS7650E Electronic Range/Oven
  • 4 burner elements
  • Self-cleaning oven
  • TOUCHMATIC electronic range control
  • Extra-large viewing window
  • Closed door broiling
  • INSTA-BROIL system with infrared heat

What is the timer/clock part number for the Amana ARGS7650E Electronic Range/Oven?

Timer part number 31944801, 1130766ne or AP4041311 for Amana ARGS7650E Stove

The ARGS7650E Electronic Range/Oven uses timer part number 31944801, 1130766ne or AP4041311. This part has been permanently discontinued by the manufacturer.

Do you have a failed Amana ARGS7650E Electronic Range/Oven control panel? Click Here:

Request Appliance Timer Service

We can repair or replace your faulty Amana ARGS7650E Electronic Range/Oven timer.

Schematic Diagram for Amana ARGS7650E Range

Amana ARGS7650E Range Schematic Diagram
Click image to enlarge

Appliancetimers.com Service requests for Amana ARGS7650E Electronic Range/Oven Timer

CityManufacturerModel NumberPart NumberFailure CodeProblem DescriptionResolution
Chestnut Hill, MassachusettsAmanaARGS7650E31944801N/Atimer separated from black overlay so buttons could not be operated. and when operating buttons the UP arrow seems to be inoperative.Repaired
ZION, IllinoisAmanaARGS7650E31944801N/ABlack Tab broken off the bottom of the unit.Replaced with reconditioned timer
Seaside, CaliforniaAmanaARGS7650E31944801N/AIf I unplug my range and plug it back in the controller works for a minutes and then goes dead again. Evidently, this part is now obsolete and you are my only hope for repair. Let me know I, by some chance, you have one of these instock.Replaced with reconditioned timer
Seaside, CaliforniaAmanaARGS7650E31944801N/Aold one dead. need new one.Replaced with reconditioned timer
Laona, WisconsinAmanaARGS7650E31944801No DisplayPower to control - No displayRepaired
ChrstianstedAmanaARGS7650E31944801noneIf you set the time it will run for awhile and then switch to flashing display and ususally loose a couple of minutes of time.
If you set the oven to bake and select a temp, the oven may or may not come on but most of the time it does, then it heats up to some intermediate temp like 200 degrees and stops. Then if I go through the steps to bake again it will start and continue to heat up to the required tempertaure. Sometimes it will continue baking and many times it will stop baking and cool down. i have baked things for 20 minuters or so that way sometimes. I don't know if the broiler works or not because the igniter is broken for the broiler and I haven't got the new part yet but I would bet that it is eratic as the clock and the oven side
Repaired
Edwards, ColoradoAmanaARGS7650E31944801unknown (5 54?)Does not operate the oven any longer. Continuous blink with a clock time - 5:54 (I think). Never saw a failure code. Stove top continues to operate. Thank you.
If unable to repair, do you have a reconditioned or new one as a replacement? Last time I checked you did not. Also - FEDEX will not recognize my physical address so it may have to ship via United Parcel. Let's talk via email after your assessment. Ok?
Repaired
Washington, District of ColumbiaAmanaARGS7650E31944801N/AWill not come on at all.Replaced with reconditioned timer
Edwards, ColoradoAmanaARGS7650E31944801unknown (5 54?)Does not operate the oven any longer. Continuous blink with a clock time - 5:54 (I think). Never saw a failure code.Repaired
Dorchester, MassachusettsAmanaARGS7650E31944801.N/ATurned oven o9n, small flash iof light then a puffof smoke. Oven dead.Repaired
Bexley, OhioAmanaARGS7650E793360N/ATimer and oven do not workAwaiting receipt of timer
Columbia, PennsylvaniaAmanaARGS7650E (P1130755N E)N/AN/AN/AAwaiting receipt of timer
Syracuse, New YorkAmanaARGS7650E316653BN/APart separated from range unit - needs replacement, and repair service says part no longer availableRepaired
Syracuse, New YorkAmanaARGS7650E316653BN/AThe plastic attachments to the Electronic Control Panel and faceplate have broken, making it impossible for the buttons to be pushed.Repaired
Anchorage, AlaskaAmanaARGS7650E - P1130759NEY03155669N/AOld timer no longer responds and plastic pieces are breaking apart.Awaiting receipt of timer
Seattle, WashingtonAmanaARGS7650E (P1130762NE)31-315569-07-0 100-969-00 585/905'F99055643 GASnoneDisplay is blank. Cycled power no help. No sound when any button is pressed. No Oven controlRepaired
Dorchester, MassachusettsAmanaARGS7650E30944801noneStarted ove,, smell of electronics burning, puff of smoke then blank.Repaired
Three Rivers, CaliforniaAmanaARGS7650E? maybe PS7985None presentedturns on / lights up but temp. does not rise. Oven does not light. Put new glow plugs in a couple of years ago.Repaired
Grass Valley, CaliforniaAmanaARGS7650EPS79785, Sears p/n 0315569N/APin 4 of J5 overheated and pulled out; please replace the connector and check the full operation; if you can't replace J5, please solder a wire to the trace and I will use that instead. This is the last chance as I cannot find a replacement control. I will enclose a schematic; not sure if it is the exact one; but,it's close.Repaired

Common ARGS7650E timer/clock/ERC problems

I have a Amana gas oven model #ARGS7650E that had a short from the oven light. The circuit breaker did not trip but I have no electrical functions.
How do I get at the spark module to replace it in an Amana gas oven, model # XXXXX? From the back? From below?
I have an Amana Gas oven (ARGS7650E). The digital control display panel became detached on one side from the front metal casing and is now pushed back into the space behind it. How do I access the space behind the digital display?
I have an Amana gas oven: Model ARGS7605E. It has an electronic, digital clock/controller for the oven temp, selection (oven, broil), and the controller is not working. It clearly needs a new digital controller, but the parts ordering sites say it is no longer made. Except for this problem it is a fine oven. Is it possible for some other part to work or am i out of luck and have to purchase an entire new oven? If so, you can be it won't be an Amana. Mike
Amana Model ARGS7650E Oven Problem I have an Amana Model ARGS7650E. The top burners and the broiler all work fine. The oven igniter comes on and heats up, but the gas doesn't come on. Even when holding a cigarette lighter to the burner, it doesn't light.
bad electronic contral panel on Amana gas oven I have a 1998 Amana ARGS7650E with an electronic control panel that just quit working (so the oven is useless!). I am told by a repairman that this control panel is no longer available through the manufacturer. Any advice?
Trouble with an Amana oven posted by Ricky101 on Jun 06, 2008 Report abuse I have an Amana Model ARGS7650E. The top burners and the broiler all work fine. The oven igniter comes on and heats up, but the gas doesn't come on. Even when holding a cigarette lighter to the burner, it doesn't light. Comment by Ricky101, posted on Jul 26, 2008 I replaced the gas valve. While the burner comes on now, it doesn't light fast and we smell gas. Also, it is very slow to heat up. Watching the burner with the cover removed and the door closed, the flame will go from full to very small and back again. Not very fast and mostly the flame will just barely be visible most of the time.
Trouble with an Amana oven I have an Amana Model ARGS7650E. The top burners and the broiler all work fine. The oven igniter comes on and heats up, but the gas doesn't come on. Even when holding a cigarette lighter to the burner, it doesn't light.
